                              CROSBY S 279 Eye Bolts

                              CROSBY S 279 Eye Bolts
                              CROSBY S 279 Eye Bolts
                              Product Code : S 279
                              Brand Name : CROSBY EYE BOLTS
                              Product Description
                              • Forged Steel.
                              • Working Load Limits shown are for In-line pull.
                              • Fatigue rated at 1-1/2 times the Working Load Limit at 20,000 cycles.
                              • Crosby products meet or exceed all the requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
                              • Recommended for in line pull.
                              • S-279 threaded UNC.
                              • M-279 metric threaded

                              Size

                              Stock No.

                              Working  Load Limit * (lbs.)

                              Weight per 100
                              (lbs.)

                              Dimensions (in.)

                              A** Thread

                              B

                              C

                              D

                              E

                              F

                              G

                              H

                              1/4 x 1

                              9900182

                              650

                              5.00

                              1/4 - 20

                              1.02

                              1.13

                              .75

                              2.29

                              .19

                              .53

                              .70

                              5/16 x 1-1/8

                              9900191

                              1200

                              9.00

                              5/16 - 18

                              1.15

                              1.38

                              .88

                              2.74

                              .25

                              .59

                              .90

                              3/8 x 1-1/4

                              9900208

                              1550

                              15.00

                              3/8 - 16

                              1.27

                              1.62

                              1.00

                              3.07

                              .31

                              .69

                              1.00

                              1/2 x 1-1/2

                              9900217

                              2600

                              28.00

                              1/2 - 13

                              1.53

                              1.95

                              1.19

                              3.70

                              .38

                              .91

                              1.20

                              5/8 x 1-3/4

                              9900226

                              5200

                              55.00

                              5/8 - 11

                              1.79

                              2.38

                              1.38

                              4.45

                              .50

                              1.13

                              1.47

                              3/4 x 2

                              9900235

                              7200

                              96.00

                              3/4 - 10

                              2.05

                              2.76

                              1.50

                              5.07

                              .63

                              1.38

                              1.64

                              7/8 x 2-1/4

                              9900244

                              10600

                              154.00

                              7/8 - 9

                              2.31

                              3.25

                              1.75

                              5.87

                              .75

                              1.56

                              1.94

                              1 x 2-1/2

                              9900253

                              13300

                              238.00

                              1 - 8

                              2.57

                              3.76

                              2.00

                              6.66

                              .88

                              1.81

                              2.21

                              1-1/4 x 3

                              9900262

                              21000

                              399.00

                              1 1/4 - 7

                              3.09

                              4.50

                              2.50

                              7.95

                              1.00

                              2.28

                              2.61

                              1-1/2 x 3-1/2

                              9900271

                              24000

                              720.00

                              1 1/2 - 6

                              3.60

                              5.50

                              3.00

                              9.49

                              1.25

                              2.75

                              3.14

                              * Ultimate Load is 5 times the Working Load Limit. Maximum Proof Load is 2 times the Working Load Limit
                              ** All Bolts Threaded UNC

                              M-279 Metric

                              Size

                              Stock No.

                              Working  Load Limit * (kg)

                              Weight per 100 (kg)

                              Dimensions (mm)

                              A** Thread

                              B

                              C

                              D

                              E

                              F

                              G

                              M 6

                              1045753

                              200

                              .03

                              M6 x 1.0

                              13.0

                              28.7

                              19.1

                              58.0

                              4.9

                              13.5

                              M 8

                              1045789

                              400

                              .05

                              M8 x 1.25

                              13.0

                              35.1

                              22.4

                              59.7

                              6.4

                              15.0

                              M 10

                              1045833

                              640

                              .08

                              M10 x 1.5

                              17.0

                              41.1

                              25.4

                              78.0

                              7.9

                              17.5

                              M 12

                              1045869

                              1000

                              .18

                              M12 x 1.75

                              20.5

                              49.5

                              30.2

                              94.0

                              9.7

                              23.1

                              M 16

                              1045913

                              1800

                              .4

                              M16 x 2.0

                              27.0

                              60.5

                              35.1

                              113

                              12.7

                              28.7

                              M 20

                              1045995

                              2500

                              .90

                              M20 x 2.5

                              30.0

                              70.0

                              38.1

                              129

                              16.0

                              35.1

                              M 24

                              1046029

                              4000

                              .95

                              M24 x 3.0

                              36.0

                              95.5

                              51.0

                              169

                              22.4

                              46.0

                              M 30

                              1046075

                              6000

                              1.6

                              M30 x 3.5

                              45.0

                              114

                              53.5

                              202

                              25.4

                              58.0

                              M 36

                              1046109

                              8500

                              2.7

                              M30 x 4.0

                              54.0

                              140

                              76.0

                              241

                              31.8

                              70.0

                              * Ultimate Load is 5 times the Working Load Limit. Maximum Proof Load is 2 times the Working Load Limit

                              ** On Request: Special threading, as forged bolts for customer conversion
