Liftit Low Height Hydraulic RMC 201 Ton Button Jack
29200 INR/Set
Product Details:
- Accessories Coupler with dust cap
- Connectivity Type Hydraulic Coupling
- Features Ultra Low Height, Heavy Duty, Robust Design, Portable
- Application Construction, Heavy Machinery Lifting, Maintenance, Industrial Applications
- Flow Rate Depends on pump specification
- Temperature Range -20C to +60C (Typical)
- Power Source Hydraulic Manual or Electric Pump (not included)
- Click to View more
X
Liftit Low Height Hydraulic RMC 201 Ton Button Jack Price And Quantity
- 29200.00 - 29200.00 INR/Set
- 29200 INR/Set
- 1 Set
Liftit Low Height Hydraulic RMC 201 Ton Button Jack Product Specifications
- Construction, Heavy Machinery Lifting, Maintenance, Industrial Applications
- Not Applicable (Hydraulic)
- Standard (Varies per application)
- Other
- Lifting Heavy loads
- Depends on pump specification
- 700 Bar (rated)
- Other
- High, Designed for Heavy Lifting and Compact Spaces
- Compact, Cylinder Shape
- Flat/Base Mount
- -20C to +60C (Typical)
- Coupler with dust cap
- Ultra Low Height, Heavy Duty, Robust Design, Portable
- Hydraulic Coupling
- Industrial Hydraulic Button Jack 20 Ton
- Hydraulic
- Hydraulic Manual or Electric Pump (not included)
- 2.7 Kilograms (kg)
- High-pressure Seals
- yellow
- Spring Return
- 11 mm
- Industrial Yellow Powder Coating
- Overload Protection Mechanism
- Easy to Handle
- Corrosion Resistant
- Ultra Low Profile
- Low, Periodic Inspection Required
- RMC-201L
- Custom to 201 Ton Specification
Liftit Low Height Hydraulic RMC 201 Ton Button Jack Trade Information
- Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID)
- 100 Set Per Day
- 1 Days
- Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia
- All India
Product Description
Liftit Low Height Hydraulic Button Jack RMC 20 Ton
Technical Details :-
Load Lifting Capacity - 20 Tons
Stroke Length - 11 mm
Oil Capacity - 0.031 Ltr
Collapsed Height - 52 mm
Extended Height - 63 mm
Outside Dia - 100 x 77 mm
Weight - 2.7 Kg
These Button Jack cylinders have been designed to combine minimum collapsed height with Minimum strokes to Accurately Level the job in millimeter Size accuracy These Hydraulic Button Jacks can be used in a wide variety of situations such as routine maintenance, production, industrial body building, frameworks, shipyards heavy civil constructions such as bridges these can also be used in hydraulic presses and other special purpose. These Flat Jacks Single Acting, Spring Return are ideal for areas where closed height is a constraint and are suited for pushing, raising, separating and lowering of viaduct structures - bridges and crane repairs, site maintenance, aligning and lowering of heavy machinery, lifting of motors. Features: Designed for Applications Requiring Low Height, Low Lift, Portability and Easy Positioning Heat Treated Alloy Steel Body Ram Returns By Spring, Allows use in any position Hard Chrome Plated Ram for Corrosion Resistance Provided With Mounting Holes For Fixing.
Ultra-Low Profile for Tight Spaces
The RMC-201L jack's ultra-low collapsed height allows it to operate in confined areas where traditional jacks cannot reach. Its compact, flat-mount cylinder design and high-pressure hydraulic seals ensure maximum performance, even when space is restricted. Ideal for use in complex machinery setups, construction foundations, and industrial maintenance tasks.
Exceptional Lifting Capacity and Reliability
Designed to lift up to 201 tons, this jack stands out for its impressive capacity and reliable performance. The robust cylinder bore is customized for the 201-ton specification, while heavy-duty materials and overload protection mechanisms enhance safety during operation. Its spring return feature ensures effortless retraction after each lift, simplifying workflow and boosting productivity.
Corrosion-Resistant and Easy to Maintain
With an industrial yellow powder coating and corrosion-resistant surface treatment, the RMC-201L performs reliably in demanding environments. Maintenance is minimal, requiring only periodic inspections, while its high-pressure seals and excellent design help reduce wear and extend service life. The included coupler with dust cap aids in keeping the hydraulic connection clean and efficient.
FAQ's of Liftit Low Height Hydraulic RMC 201 Ton Button Jack:
Q: How is the Liftit RMC-201L Button Jack used for heavy lifting?
A: The jack is positioned under the load and connected to a hydraulic manual or electric pump (not included) via the hydraulic coupling. When operated, hydraulic pressure is applied, lifting the heavy object up to its 11 mm maximum travel. Once lifting is complete, the spring return mechanism safely retracts the jack.Q: What safety features does this hydraulic jack offer?
A: For enhanced operator protection, the RMC-201L is equipped with an overload protection mechanism that prevents operation if the load exceeds its 201-ton rated capacity. This reduces the risk of jack failure or accidents in high-pressure lifting scenarios.Q: When should periodic inspection or maintenance be performed?
A: Regular inspections are recommended according to usage intensity-typically before each use for critical operations or monthly for routine applications. Check for seal integrity, proper functioning, and any signs of wear or corrosion to ensure the jack's performance and longevity.Q: Where is this jack suitable for application?
A: The RMC-201L excels in construction, heavy machinery lifting, industrial maintenance, and any scenario where space is limited but heavy loads must be raised. Its compact form and portability make it suitable for both indoor and outdoor use on worksites across India.Q: What is the process for connecting the jack to a pump?
A: Attach the jack's coupler (with included dust cap) to a compatible hydraulic pump using the standard hydraulic coupling. Ensure all connections are secure and free of debris before operating, and verify the pump's flow rate and pressure suitability with the jack's 700 Bar operating specification.Q: What benefits does the corrosion-resistant finish provide?
A: The industrial yellow powder coating with additional corrosion-resistant treatment extends the jack's service life, reduces maintenance needs, and ensures consistent performance even in harsh environments, reducing downtime and operating costs.Tell us about your requirement
