LIFTIT Magnetic lifter 2000 Kg

Product Description

Zero electricity required
Forged hook for high mechanical strength and durability
Precision machined assembly block in a single piece to enhance efficiency
Designed for safety and lightweight
Full proof locking system with an easy to use "on" and" off" lever
3 times rated capacity factor of safety to meet the safety standards as per international standards for under the hook devices
Test certificate for safety factor from government-approved third party
No Maintenance and Operating cost
No damage to the work piece being lifted
Very Compact

Benefits
Lifting Magnets use space more effectively. Eliminates the need to gauge and increase stacking height
As less as one operator can move large and heavy work-piece safely and easily using Magnetic Lifters
Lifting Magnets save labor and time - improves productivity

Construction

LIFTIT Permanent Magnet Lifters have a strong magnetic field path produced bindermagnetic materials.

"On" and "Off" of the magnetic path is controlled by turning the lever manually.
There are shackles on the top of Magnetic Lifter for lifting.

Operating Instruction
The work piece surface(magnetic ferrous surface) and the magnet pole surface must be clean and smooth to achieve maximum efficiency. Ground and machined surface are ideal but a good clean surface on a ferrous or casting is acceptable provided a sufficiently flat area available for a good magnetic contract with the work piece

There should be no air gap/inclusions between the magnet pole and the job surface

Place the magnet on the ferrous surface. Unlock the lever by pulling it out and then turn it to the ON position. Once it is made ON, lock it by releasing it. For making it OFF, please follow the similar procedure. (Do not place on wooden surface OR non-magnetic surface - it will not be possible to operate Lever to ON position)

Move the load smoothly,avoid shocks and collisions

To place/drop the lifted material, operate the lever to the "OFF position

Safety Instruction
Place the magnet on the Ferrous Surface in the "OFF position and then make it "ON. Do not make it ON without keeping it on a ferrous surface
The magnet is to be placed on the center, i.e. centering to the center of gravity of the load and then lift
While handling the load, no person should be allowed in the immediate danger zone
Ensure that the lever is made "OFF after resting the load at the desired place in the balance position

When Not In Use
Apply Grease / Oil on Magnetic Poles surface to prevent it from rusting and
Place it on a thick wooden plank to safeguard its Magnetic poles from any damages, scratches, etc.

Why LIFTIT Permanent Magnetic Lifters?
LIFTIT magnetic Lifters are ruggedly built
High Lifting Capacity with respect to size & weight
Works without Electrical Power
No maintenance and operational costs
Very easy to use - Save time & energy
Made with high energy rare earth magnets (NdFeB)
Mechanical Switching by turning a lever with a lock
The system against switching off accidentally
No damage to the work piece being lifted
Easily transportable
Reliable

Dimension and Specification
Model - LIFTIT Permanent Magnetic Lifter
Lifting Capacity - 2000 Kg
Max Pulling Power - 6000 Kg
Self weight - 62 Kg
L - 360 MM
B - 155 MM
H - 160 MM
R - 370 MM
